Rhino Ultra Non-Silenced EC Fan

Rhino Ultra Non-Silenced EC Fan

Regular price £83.33
Regular price Sale price £83.33
Sale Sold out
Taxes included. Shipping calculated at checkout.

Description

The Rhino Ultra EC fan (non-silenced) is a compact, energy-efficient inline extractor that punches well above its size. Its EC motor and mixed-flow impeller deliver strong airflow at high pressure while using less power than a comparable AC fan.

Speed is fully adjustable from 0 to 100% using the Varispeed controller supplied in the box, and a soft start brings the motor up to speed gently to protect it and your electrics. If you want more control, the fan also works with Rhino's EC controllers and, using the cables supplied, with controllers that have RJ45 or 3-pin connections.

Key features

  • EC motor with mixed-flow impeller: high airflow at high pressure
  • Fully variable speed, 0 to 100%
  • Varispeed speed controller included
  • Connection cables supplied for RJ45 and 3-pin controllers
  • Soft start function
  • Sealed steel body
  • Built-in mounting bracket for easy fitting
  • Uses less power than a comparable AC fan

Technical specifications

Size Max airflow Power Max speed Noise Static pressure IP rating
100mm (4") 275 m³/h 18W 5,000 RPM 56.8 dB(A) 334 Pa IPX2
125mm (5") 280 m³/h 20W 5,000 RPM 54.4 dB(A) 350 Pa IPX2
150mm (6") 594 m³/h 40W 5,000 RPM 60 dB(A) 500 Pa IPX2
200mm (8") 1,205 m³/h 75W 3,800 RPM 62 dB(A) 520 Pa IPX2
250mm (10") 1,808 m³/h 150W 3,200 RPM 65 dB(A) 510 Pa IPX2
315mm (12") 2,987 m³/h 320W 3,000 RPM 78 dB(A) 677 Pa IPX2

Figures are Rhino's maximum ratings. Real-world airflow, noise and pressure depend on your controller, ducting and filter.

Good to know

  • The fan needs a controller connected to run.
  • Need it quieter? See the Rhino Ultra Silenced EC fan, which has an acoustic-lined body.
  • Match it with a Rhino Pro or Rhino Hobby carbon filter of the same flange size.
